Made to Stand
Mastsystem is one of the world-leading suppliers of robust, high-performance tactical composite mast systems
Contact usSkyhigh: Built to carry
SkyHigh vehicle mast sets the bar within the vehicle mast standard. The product’s unique design makes it possible for it to carry top loads of up to 600 kgs while having an ideally lightweight composite structure. The trustworthy vehicle mast is highly durable and four times faster to set up than our previous designs.
Ready to serve
SkyHigh can be installed inside or outside your vehicle or shelter with several mounting options. Excellent lifting capability in comparison to its compact size.
Easy to use
The mechanical structure guarantees reliable performance with minimal maintenance and low lifecycle cost. Save space with SkyHigh’s compact footprint.
Smart and swift
The 20 m mast is deployable in less than 2 minutes (1min 40sec). Pre-adjusted height control, slope monitoring and modern computer-controlled user interface. Intelligent built-in maintenance diagnostics.
When Every Second Counts
Excellent lifting capability for heavier top loads – when there’s no time to waste
THE SMART VEHICLE MAST SYSTEM
The fast, easy-to-use mast has been designed to have long maintenance intervals, combined with a maintenance-friendly structure. Moreover, with features like pre-adjusted height control, slope monitoring, and a modern computer-controlled user interface, SkyHigh sets a new standard for future vehicle masts. Its’ smart memory saves important user data, such as deployment counter and maximum forces – these features make SkyHigh our smartest vehicle mast yet.
Designed to function perfectly even in extreme conditions and abrupt situations – SkyHigh is the perfect vehicle mast system when there’s no time to waste.
Mastsystem
Combat-proven in the toughest conditions, Mastsystem’s telescopic mast systems, antenna positioners, vehicle mounting kits, and other accessories have earned their enviable reputation for rugged reliability and superior performance in the arctic-, tropical- and desert environments. Mastsystem is located in the arctic surroundings of Finland and has been delivering for almost four decades with a consultative sales approach, ensuring that every customer gets the best solution for their needs.
Mastsystem Int’l Oy’s quality- and environmental management system fulfills the requirements of ISO 9001, ISO 14001, and AQAP 2110 standards. Masts and accessories have been proven to meet the environmental requirements by the MIL-STD 810 and DEF STAN 00-35.
Trusted by the Finnish Defense Forces
SKYHIGH-Masts
| SH333/2,5-1,7 | SH333/3-1,4 | SH333/6-2,1 | SH333/8-2,3 | SH333/10-2,4 | SH333/12-2,8 | SH333/15-3,0 | SH333/18-3,2 | SH333/20-3,3 | |
|---|---|---|---|---|---|---|---|---|---|
| EXTENDED HEIGHT (M) | 2.5 | 3 | 6 | 8 | 10 | 12 | 15 | 18 | 20 |
| RETRACTED LENGTH (M) | 1.7 | 1.4 | 2.1 | 2.3 | 2.4 | 2.8 | 3.0 | 3.2 | 3.3 |
| SECTIONS (PCS) | 2 | 3 | 4 | 5 | 6 | 6 | 7 | 8 | 9 |
| MAX.TOP LOAD (KG) | 600 | 400 | 350 | 263 | 191 | 161 | 100 | 61 | 50 |
| DEPLOYMENT TIME (MIN:S) | 0:40 | 0:40 | 1:00 | 1:10 | 1:10 | 1:30 | 1:35 | 1:40 | 1:40 |
